Sky-Watcher EQ5 Pro SynScan GoTo Mount & Tripod

Sky-Watcher EQ5 Pro SynScan GoTo Mount & Tripod — 20981

The Sky-Watcher EQ5 Pro SynScan GoTo Mount is a highly capable, computerised equatorial mount designed for serious visual observers and ambitious astrophotographers. Combining excellent stability with precision GoTo technology, it offers accurate tracking, straightforward alignment and impressive payload support — making it one of the most popular mid-range astronomy mounts available.

Perfect for medium-sized refractors, reflectors and Maksutov/Schmidt-Cassegrain telescopes, the EQ5 Pro delivers the accuracy and reliability needed for long observing sessions and guided imaging.

Computerised GoTo control with SynScan

Supplied with the SynScan V3 updatable handset, the EQ5 Pro allows you to automatically slew to and track thousands of night-sky objects at the touch of a button. Firmware can be updated via the internet, ensuring continued compatibility and feature upgrades.

Key SynScan features include:

• Pointing Accuracy Enhancement (PAE)

• Storage of alignment data

• Support for optional GPS accessories

• User-friendly menu guided alignment

• Huge object database with over 42,900 objects

Choose from one-, two- or three-star alignment and be observing in minutes.

Smooth tracking & precise motion

The EQ5 Pro uses high-precision stepper motors and micro-step motor control for smooth, accurate motion. With multiple slewing speeds and fine control, it’s ideal for both visual use and astrophotography.

• Resolution: 0.288 arc-second

• Slew rates: 0.5× to 800×

• Tracking rates: Sidereal, Lunar & Solar

• Tracking mode: Right Ascension (R.A.) tracking

Support for ST-4 autoguiders, backlash compensation and Periodic Error Correction (PEC) help keep your targets centred during longer exposures.

Strong, stable and ready for imaging

Engineered for rigidity and vibration control, the EQ5 Pro offers excellent stability for telescopes up to approximately 9kg in payload. The included steel-leg tripod provides a secure foundation, even when fully extended.

Power is supplied via 11–15V DC (2A), making it easy to run from a dedicated power tank in the field.

Connectivity & software compatibility

The EQ5 Pro features a premium PC interface compatible with ASCOM, allowing control via popular astronomy software and planetarium programs. It also supports the NexStar-5i protocol for added flexibility.

User-adjustable LCD contrast, LED backlight and buzzer volume make the handset comfortable to use in all conditions.

Object database & catalogues

Browse and select from:

• Messier

• NGC

• IC

• Caldwell catalogues

• Planets, double stars, variable stars

• User-defined targets and more

Technical specifications

• Mount type: German equatorial GoTo

• Handset: SynScan (firmware updatable)

• Payload capacity: approx. 9kg

• Autoguider: ST-4 port (0.25×, 0.5×, 0.75×, 1× guiding)

• Power: 11–15V DC, 2A (tip positive)

• Alignment methods: 1-, 2-, 3-star

• Pointing accuracy: up to 1 arc-minute

• Additional features: PEC, backlash compensation, GPS-ready

Power supply not included.

The Sky-Watcher EQ5 Pro SynScan GoTo Mount and Tripod is an outstanding all-rounder — stable, accurate and future-ready. Whether you’re upgrading from a manual mount or building a capable astrophotography setup, it delivers performance and convenience that will grow with you for years to come.
